Sizes

• Widths –
  20’, 24’, 30’, 36’ & 40’ standard
  Custom widths available, add on adaptions available
• Lengths –
  Any length in 12’ increments, custom lengths available
• Heights –
  8’ to 16’ at eaves
• Roof slope –
  3/12 standard, custom slopes available

Structural Components

•  Posts –
  8’, 9’ & 10’ eaves: 12 ga. galvanized 2’ x 3-¼’ C-profile
  11’ & 12’ eaves: 12 ga. galvanized 3-½’ x 3-½’ C-profile
  13’ & 14’ eaves: 11 ga. galvanized 3’ x 3’ square tubing
  15’ & 16’ eaves: 9 ga. galvanized 4’ x 4’ square tubing
• Roof & Side Purlins-
  2-3/8’ high, 14 ga. galvanized hatbox channel
• Wind Bracing –
  ¼’ galv. cable with 5/16’ eyebolts
• Concrete Foundation –
  Either 16’ x 3’ deep concrete piers with posts embedded in concrete or anchor bolts in built up slab edges


Roof Structure

• Welded trusses of 12 ga., 14 ga. & 16 ga. channel bolted to posts & at center of truss with 1-½’ HDG bolts.



• Square tubing diagonal bracing at each gable

Available Extras

Walk-in doors, overhead doors, windows, insulation, concrete slabs and truck-wells.

Coverings

• 29 ga. or 26 ga. metal galvanized, galvalume or painted/galvalume



• Available in Pro Panel (residential or agricultural) or PBR Panel (commercial)

• Variety of colors for panels, trim & fasteners

• Trim includes: ridge cap, inside & outside corners, gable flashing, J-trim, gutters, downspouts & skylight

Side and Endwall Treatment

• Fully sheeted, open or a combination


Engineering

Imperial channel truss structures meet or exceed the ‘Florida Building Code’ Requirements
